Delta TP70P-211LC1T User Manual

Chapter 2 Specifications and Functions
2-15
2__
2.2.4.3 Electrical Specifications for Load cell Terminals
Model
Item
TP70P-211LC1T / TP04P-20EXL1T
Input Signal Range
±300 mVDC (when the excitation voltage is at 5 VDC)
Sensibility (Variable
excitation voltage)
+2 ~ 9.5VDC ±5%
ADC resolution
24 bits
Highest precision
0.01%
Applicable sensor
type
4-wire or 6-wire load cell
Expanding a
temperature
coefficient
≤ ± 20ppm/K v. E
Reducing a
temperature
coefficient to zero
≤ ± 0.1μV/K
Linearity error
≤ 0.015%
Response time
2.5，10，16，20，50，60，100，200，400ms
Eigenvalue
applicable to a load
cell
0.5 ~ 256mV/V, refer to section 3.1.1 for more details
Maximum Distance
for Connecting a
Load Cell
100 meters
Maximum current
consumption
250 mA
Allowable Load
40 ~ 4,010
Ω
Average value filter
1 ~ 100
Extreme value filter
0 ~ 8
Common-mode
rejection ratio
(CMRR)
100 dB
