TP70P-211LC1T/TP04P-20EXL1T Operation Manual
2-12
Model
TP04P-20EXL1T
LCD display; shows the current status
Number Keys
0 ~ 9: can be used as number keys or user-defined function keys
(user can define function keys in TPEditor)
Use ENT key to confirm and save the setting; users can also self-define.
Command Keys
UP: Use this key to increase the setting value or go to the previous page.
DOWN: Use this key to decrease the setting value or go to the next page.
LEFT: Use this key to set up the parameters.
RIGHT: Use this key to set up the parameters.
Users can also define command keys in TPEditor.
2.2.2 Electrical Specifications
Model
TP70P-211LC1T TP04P-20EXL1T
24 VDC (-15% ~ 20%) (DC input power polarity reversal protection)
DC input power polarity reversal protection
> 5 MΩ (The voltage between all I/O terminals and the ground is 500 V DC.)
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8kV Air Discharge
EFT (IEC 61131-2，IEC 61000-4-4): Power Line: 2kV, Digital I/O: 1kV
Analog & Communication I/O: 1kV
Damped-Oscillatory Wave: Power Line: 1kV, Digital I/O: 1kV
RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m
Ground
The diameter of the ground used should not be less than the diameters of the wires
connected to the PLC power terminals.
(If several PLCs are used simultaneously, use single-point ground.)
3 years at a temperature of 25°C
Operating temperature
0°C~50°C
Relative humidity: 20%~90% RH (No condensation)
Panel protection rating
IP66/ NEMA4X/ UL Type4X(Indoor use
NEMA 4 / IP66
Vibration / Shock resistance
International standards IEC61131-2, IEC 68-2-6 (TEST Fc) /
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Transfer of thermal energy via convection
Removable terminal blocks
From 0 to 2000 meters above sea level
Weight
850 g 550 g
