5.4 Special Data Registers Specific for TP Series
The types and functions of special data registers (special D) for TP04P-20EXL and TP70P-211LC1T are listed
in the table below. “X” in the column of Attibute refers to un
retentive and “O” refers to retentive (latched). “◎”
indicates you need to write “
H’5678” in D4600 to have the data written into Flash and then the data is retentive.
D4530-D4699 should work with M1666 and M1667 to read or write. When M1666 is ON, the data is read for once. When
M1667 is ON, the data is written for once.
Special
Item Description Attibutes Default
D4300 IO1 channel output value K0 ~ K32000 R/W X K0
D4301 IO2 channel output value K0 ~ K32000 R/W X K0
D4304 Digital Output
H’0000 ~ H’00FF；Y20 ~ Y27
R/W X H’0
D4305 Digital Input
K0 ~ K1；X20
R X --
Current weight value
D4310 Status code
b0 (H’0001): exceeding weight upper limit
b1 (H’0002): empty
b2 (H’0004): measured value is stable
b3 (H’0008): display value (DV) is stable
R X --
D4311 Error status code
b0 (H’0001): Error exists in the power supply
b1 (H’0002): Error exists in the module
hardware
b2 (H’0004): weight exceeds the maximum
weight that can be measured or the voltage of
SEN is incorrect
b3 (H’0008): calibration error
R X --
D4312
Weight display value (DV)
Present weight value R X --
D4313
Weight display value (DV)
(High word)
Present weight value R X --
D4320 AX CH1 PV
Present weight value of CH1; when the value is
K-32765 (H8002), it indicates an error occurs
and temperature cannot be obtained
R X --
D4323 AX CH1 sensor type
K-1: channel closed
K0: 0 ~ 5 V (default)
K1: 0 ~ 10 V
R/W O K0
D4323 AX CH1 sensor type
K3: 4 ~ 20 mA
K4: 0 ~ 50 mV
K5: Pt100
K6: JPt100
K7: Pt1000
K21: Cu50
R/W O K0
