KRYPTON®
TECHNICAL REFERENCE MANUAL
3.2.2. Channel setup Krypton
When Dewesoft has started up, you will be in Measure mode and see the Setup files list or you can
create a New setup ❶ . Click on Ch. setup (on the right of Setup files) to switch to the Channel setup
mode ❷ . In the channel setup you can see a preview of the connected devices on the upper left side.
Setup files
Channel setup Krypton
Hint
When you click on a connector in the image the corresponding channel in the Channel setup
grid will automatically be selected. This also works the other way around: when you select a
channel (or multiple channels) in the setup grid, the corresponding connectors in the image will
be highlighted.
The sampling rate will be set for all connected Krypton devices: of course only up to the max. sampling
rate of the individual slices.
KRYPTON® V20-1 11 / 141
