KRYPTON®
TECHNICAL REFERENCE MANUAL
9.3. Power Junction
The Power Junction box can be used to join the Ethernet and the Power lines in a single 8-pin ECAT
cable. In the example we connect a PC to the Krypton chain. Effective use of the Power Junction is when
the Krypton devices are far away from the PC or a system and there is no power supply available (i.e. in a
temperature measurement chamber).
System with Power Junction
List of required cables:
