5.9.4. KRYPTONi-1xLV 
KRYPTONi-1xLV is a single channel low voltage module with BNC connector. 

KRYPTONi-1xLV 

5.9.5. LV: connectors 



BNC connector: pin-out (BNC) 

Pin 
Name 
Description 
1 
IN+ 
Input + 
2 
GND 
Ground 


