5.7. HV: High Voltage 

Single channel high voltage input DAQ device. Isolation category is CATII 1000V. 

5.7.1. HV: speciﬁcations 

Analog Input 

Input types 

Voltage 

Number of channels 

1 

Input connector 

4 mm safety banana jack 

ADC Type 

24-bit SAR with anti-aliasing ﬁlter 

Sampling Rate 

40 kS/sec (software-selectable) 

Input range 

±1000 V 

Input accuracy 

±0.03 % of reading ±0.2 V 

Typ. Noise ﬂoor @ 10 kS/sec 

-96 dB 

Typ. Noise ﬂoor @ 40 kS/sec 

-90 dB 

Typ. CMR @ 400 Hz / 1 kHz 



Gain Drift 



Offset Drift 



Gain Linearity 



Input Coupling 

DC 

Input Impedance 

10 MΩ 

Protection class 

CAT III 600 V, CAT II 1000 V 

Overvoltage Protection 

+-2 kVpeak 

Analog input performance 

Bandwidth (-3 dB) 

0.49 fs 

Alias-free Bandwidth 

DC to 0.453 fs 

Alias Rejection 

-100 dB (all sample rates) 

Delay Through ADC 

37 / fs 

Oversampling 

32 

Power 

Power consumption 

1 W (typ.) 

Environmental 

IP rating 

IP65 / IP67 (see 1) 

Physical 

Dimensions 

62 x 56 x 36 mm 

Weight 

300 g 

1) Depending on the mating connector types 



 

KRYPTON® V20-1 55 / 141  
