5.6. DIO: Digital Input/Output 

KRYPTON digital input/output modules are perfect choices for control applications. 

5.6.1. DIO: speciﬁcations 



KRYPTONi-16xDI, 8xDI-8xDO, 16xDO 



KRYPTONi-16xDI 

KRYPTONi-8xDI-8xDO 

KRYPTONi-16xDO 

Digital Input 

Isolated Input Channels 

16 

8 

- 

Compatibility 

CMOS Conﬁguration 

- 

Input low level 

UIN < 0.8 V 

- 

Input high level 

UIN > 2.4 V 

- 

Input high current @ 5 V 

UIN < 1.8 mA 

- 

Input high current @ 30 V 

UIN < 6 mA 

- 

Propagation delay 

< 1 μs 

- 

Sampling rate 

Simultaneous 20 kS/sec 

- 

Overvoltage protection 

40 V continuous (65 V peak) 

- 

Isolation voltage peak 

250 V channel/ground & channel/channel 

- 

Digital Output 

Isolated Output Channels 

- 

8 

16 

Compatibility 

- 

Open collector with 10 kΩ pull-up to +5 V 

Maximum sink current 

- 

150 mA (not protected) 

Maximum switching voltage 

- 

50 V 

Propagation delay 

- 

< 20 μs 

Maximum update rate 

- 

depending on EtherCAT master 

Isolation voltage peak 

- 

250 V channel to ground, no channel to channel isolation 

General Speciﬁcations 

Environmental rating 

IP67 

Power consumption 

2 W 

Weight 

700 g 

Slice Dimensions 

213 x 39 x 56 mm 

Dimensions with Connectors 

213 x 39 x 58.2 mm 



 

KRYPTON® V20-1 47 / 141  
