Digi XBee 3 ZigBee User Manual

Frame descriptions Node Identification Indicator frame - 0x95
Digi XBee® 3 Zigbee® RF Module
298
Node Identification Indicator frame - 0x95
Description
A device receives this frame when:
n it transmits a node identification message to identify itself
n AO = 0
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data
fields Offset Description
Frame type 3 0x95
64-bit source
address
4-11
MSB first, LSB last. The sender's 64-bit address.
16-bit source
network
address
12-13 MSB first, LSB last. The sender's 16-bit address.
Receive
options
14
0x01 = Packet acknowledged
0x02 = Packet was a broadcast packet
Source 16-bit
address
15-16
Set to the 16-bit network address of the remote device. Set to 0xFFFE if
unknown.
64-bit network
address
17-24 Indicates the 64-bit address of the remote device that transmitted the
Node Identification Indicator frame.
NI string
25-26 Node identifier string on the remote device. The NI string is terminated
with a NULL byte (0x00).
Device type
29
0 = Coordinator
1 = Router
2 = End Device
Source event
30
1 = Frame sent by node identification pushbutton event (see D0
(DIO0/AD0/Commissioning Button Configuration))
2 = Frame sent after joining event occurred (see JN (Join Notification)).
3 = Frame sent after power cycle event occurred (see JN (Join
Notification)).
Digi Profile ID
31-32 Set to Digi’s application profile ID.
Digi
Manufacturer
ID
33-34 Set to Digi’s Manufacturer ID.
