Digi XBee 3 ZigBee User Manual

Over-the-air firmware/file system upgrade process for Zigbee 3.0 Upgrade End request
Digi XBee® 3 Zigbee® RF Module
333
Upgrade End request
The Upgrade End request is generated by the client after it verifies the received firmware image to
ensure its integrity and validity. If the image fails any integrity checks, the client sends an Upgrade
End request command to the upgrade server with INVALID_IMAGE as the status. If the image passes
all integrity checks, the client sends an Upgrade End request command to the upgrade server with
SUCCESS as the status.
Frame data fields Offset Example Comments
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x1E
Frame Type 3 0x91
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0xFE
8 0x00
9 0x00
10 0x00
LSB
11
0x03
16-bit source address MSB
12
0x28
LSB
13
0x2F
Source Endpoint 14 0xE8
Destination Endpoint 15 0xE8
Cluster ID MSB
16
0x00
LSB
17
0x19
Profile ID MSB
18
0xC1
LSB
19
0x05
Receive options 20 0x01
