Frame descriptions Secure Session Response frame - 0xAE

Digi XBee® 3 Zigbee® RF Module

317

Field data fields Offset Description

Source interface 4

0 = Serial port (SPI, or UART when in API mode)

1 = BLE

2 = MicroPython

Data 5 Variable length user data.

Example

This example frame would be received if a message of “Relay Data” was sent from MicroPython to the

serial port interface.

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x0C

Frame type 3 0xAD

Source Interface 4 0x02

Data 5 0x52

6 0x65

7 0x6C

8 0x61

9 0x79

10 0x20

11 0x44

12 0x61

13 0x74

14 0x61

Checksum 15 0xB9

Secure Session Response frame - 0xAE

Description

This frame is output as a result of the Secure Session Control frame - 0x2E attempt. It indicates

whether the 0x2E frame operation was successful or not.
