Over-the-air firmware/file system upgrade process for Zigbee 3.0 Image Notify

Digi XBee® 3 Zigbee® RF Module

322

Image Notify

The server sends the Image Notify message to the client informing the device of the presence of an

update image. The Image Notify message is sent when the upgrade process is initiated from the

server.

Create the Image Notify request

The Image Notify Request is an explicit transmit frame (0x11 type) passed into the server with the

following information:
