DITEC LCA85 User Manual

37
IP2371EN
9.5.1 Additional configurable BO level parameters available with →
enabled
RO - Radio operations
Display Description
Selections
available
C1, C2, C3, C4 - Selection of CH1, CH2, CH3, CH4 function of stored remote control
NO - No setting selected
1-3 - Opening command
1-4 - Closing command
1-5 - Step-by-step command
P3 - Partial opening command
LG - Command to switch the courtesy light on/off
1-9 - STOP command
If even just one (any) CH key of the remote control is stored, the opening or step-
by-step command is implemented.
NOTE: the (opening) and (step-by-step) options are available as
alternatives, and depend on the selection
→ .
If 2-4 CH keys of a single remote control are stored, the functions matched in the
factory with the CH keys are as follows:
• CH1 = opening/step-by-step command;
, (depending on parameter );
• CH2 = partial opening command;
;
• CH3 = command to switch on/off the courtesy light;
• CH4 = STOP command; .
ER - Deletion of a single remote control
→→
2”
ENTER
EA - Total deletion of the dedicated part of the storage used by remote controls
→→
→
2”
ENTER
2”
ENTER
RE - Setting memory opening from remote control
OF - Disabled
ON - Enabled When enabled (ON), the remote programming is activated.
To store new remote controls without using the control panel, refer to the remote
control instructions.
NOTE: make sure you do not accidentally memorise unwanted remote controls.
EP - Setting coded messages
If the possibility to receive coded messages is enabled, the control panel will be
compatible with remote controls of the “ENCRYPTED” type.
MS - Backward compatibility setting with older generation GOL4 remote controls.
OF - Compatibility with old generation GOL4 and new ZEN remote controls.
ON - Compatibility with ZEN series remote controls
NOTE: MS=ON is recommended if only ZEN series remote controls are used
on the system.
