Dräger Polytron Pulsar 2 User Manual

Electrical Installation
13
Cable run in metres: To Receiver only
Worst case supply: 20V 21V 22V 23V 24V 25V 26V...32V
1 mm
2
: 210 280 350 420 490 559 629
1.5 mm
2
: 315 420 524 629 734 839 944
2.5 mm
2
: 524 699 874 1049 1224 1399 1573
4 mm
2
: 839 1119 1399 1678 1958 2238 2517
18 AWG: 173 230 288 345 403 460 5118
17 AWG: 218 290 363 435 508 581 653
16 AWG: 275 366 458 549 641 732 824
15 AWG: 346 462 577 692 808 923 1039
14 AWG: 437 582 728 873 1019 1164 1310
13 AWG: 551 734 918 1101 1285 1468 1652
12 AWG: 694 926 1157 1388 1620 1851 2083
11 AWG: 875 1167 1459 1751 2043 2334 2626
10 AWG: 1104 1472 1840 2208 2576 2944 3312
Cable run in feet: To booth Transmitter AND Receiver
Worst case supply: 20V 21V 22V 23V 24V 25V 26V...32V
1 mm
2
: 242 322 403 484 564 645 725
1.5 mm
2
: 363 484 605 725 846 967 1088
2.5 mm
2
: 605 806 1008 1209 1411 1612 1814
4 mm
2
: 967 1290 1612 1935 2257 2580 2902
18 AWG: 199 265 332 398 464 531 597
17 AWG: 251 335 418 502 586 669 753
16 AWG: 317 422 528 633 739 844 950
15 AWG: 399 532 665 798 931 1064 1197
14 AWG: 503 671 839 1007 1174 1342 1510
13 AWG: 635 846 1058 1269 1481 1692 1904
12 AWG: 800 1067 1334 1601 1867 2134 2401
11 AWG: 1009 1346 1682 2018 2355 2691 3027
10 AWG: 1273 1697 2121 2545 2969 3393 3818
