Dräger Polytron Pulsar 2 User Manual

The Handheld Terminal
36
The GC2 handheld Terminal Certification Label Explained
Plymouth UK
HANDHELD TERMINAL TYPE GC2
Serial Number
XXXXXX/YY
Flying
lead
& free
plug
Comms
Port
Um
= 250V
N/A
Um
= 0
Ui = 0
Uo = 8.4V
Io = 15.1mA
Po = 27mW
II 2 G
Li = 60μH
Ci = 0
Lo = 120mH
Co = 6.8μF
BATTERY: ALKALINE, DURACELL OR PROCELL MN 1604 / PC1604.
Warning: To prevent ignition of a hazardous atmosphere, batteries
must only be changed in an area known to be nonhazardous.
STATIC HAZARD: CLEAN ONLY WITH A MOIST CLOTH.
Non-Hazardous
Area
Hazardous Area
Ex ia IIC: Class I, Zone 0: Class I, Groups A, B, C, D;
T3C (Tamb -20
o
C to 45
o
C) T3 (Tamb -20
o
C to 60
o
C)
AEx ia IIC: Class I, Zone 0: Class I, Groups A, B, C, D;
T3C (Tamb -20
o
C to 45
o
C) T3 (Tamb -20
o
C to 60
o
C)
Intrinsically Safe.
SÈcuritÈ IntrinsËque.
Vmax = 0
Voc = 8.4V
Isc = 15.1mA
Imax = 0
Li = 60μH
Ci = 0
La = 120mH
Ca = 6.8μF
Substitution of components may impair intrinsic safety.
La substitution de composants peut compromettre la sÈcuritÈ intrinsËque.
Avertissement: Afin de prÈvenir l'inflammation d'atmosphËres dangereuses,
ne changer les batteries que dans des emplacements dÈsignÈs non dangereux.
Vmax
= 250V
Vmax
= 0
Control Drawing
GC2 94
160760
COMMS PORT
For use only in
Non-hazardous
area - do not
remove cover
location of
manufacturers
CSA
registered mark
5mm
95mm
105mm
2mm 91mm
110mm
ÿ12mm
typ 4 posn
20mm
20mm
5mm
9mm
21mm
160760
Label approved to CSAC22.2 No. 0.15
Worldmark product code SP9625.
Non- adhesive side Fine Textured
Adhesive:
3M 468MP, Pressure sensitive
Background:
RAL 9002 (Grey White) on Adhesive Side
Serial Number window to be transparent
(except for adhesive).
Text Colour: Black on adhesive side
Font: Arial, height = 2.5mm except;
Drager logo to scale
logos to scale
"HANDHELD TERMINAL _ TYPE GC2" = 3mm
"CE" height = 5mm "0518" = subscript
All un-dimensioned features to scale
Serial Number:
Text Height = 3mm minimum
To be applied by Draeger PLMS Ltd.
Single incremented
Starting No. 800000/yy
e.g. 800001/yy
800002/yy etc.
where yy is year date code
i.e. 01 = year 2001
02 = year 2002 etc
95mm
110mm
3mm
57mm
12mm
2mm
2mm
01723892.eps
Draeger PLMS Ltd.
0518
CERTIFICATE no. Sira 01ATEX2252
0518
EEx ib IIC T4 (Tamb -20
o
C to 45
o
C) T3 (Tamb -20
o
C to 60
o
C)
IEC CERTIFICATE Sira Ex01Y2278
Ex ib IIC T4 (Tamb -20
o
C to 45
o
C) T3 (Tamb -20
o
C to 60
o
C)
