4 Securing the Premises
17
4.4.1 Bypass Groups
Program frequently bypassed zones into the system as a bypass group. Using bypass groups avoids
individually bypassing each zone. One bypass group can be programmed per partition.
4.5 Arming Errors and Exit Faults
The PowerSeries Neo audibly notifies you of any errors when you are attempting to arm the system or exit
the premises.
NOTE: This feature is not to be used in UL listed installations.
To Program a Bypass Group LCD Display
1. Press to enter the function menu.
Press (*) for <>
Zone Bypass
2. Press or . If required enter your [access code].
Scroll to <>
Bypass Zones
3. Enter the [3 digit zone #] of all zones you want bypassed
OR
Scroll to and press to indicate all zones you want bypassed.
Upstrs H Wdw <>
B
4. Press to program the bypass group with the currently
bypassed zones
OR
Scroll to Bypass Options using the keys and press . Scroll to
Prg Bypass Group and press .
Press (*) for <>
Prg Bypass Group
5. The Bypass Group is now programmed. The keypad will beep three times.
Bypass Group
Programmed
6. To exit bypassing mode and return to the Ready state, press .
System is
Ready to Arm
To Load a Bypass Group LCD Display
1. Press to enter the function menu.
Press (*) for <>
Zone Bypass
2. Press or . If required enter your [access code].
Scroll to <>
Bypass Zones
3. Press
OR
Scroll to Bypass Options using the keys and press . Scroll to
Bypass Group and press .
Press (*) for <>
Bypass Group
4. The group of zones are now bypassed. The following message briefly
displays.
Bypass Group
Zones Bypassed
5. To exit bypassing mode and return to the Ready state, press .
System is
Ready to Arm
6. If using an LED or ICN series keypad, the will light and the bypassed
zones #s will be shown. If the system is ready to arm the Ready indicator
will be lit. When arming the system the following message briefly displays.
* Warning *
Bypass Active
9
9
