DSC HS2016 User Manual

35
9 Managing Troubles
9.1 Trouble Conditions
Trouble Conditions (Level 1) are comprised of various trouble types (Level 2) which may in turn be related
to a specific zone, module, device or additional type of system equipment (Level 3). For an explanation of
possible trouble conditions and the recommended actions required see Table 9-1.
When the system detects a trouble condition the following occurs:
• The Trouble indicator turns on.
• The keypad beeps once every 10 seconds.
• Press the key to silence the keypad beeps.
Examining troubles is done by pressing . When viewing troubles, the trouble indicator
flashes to identify the level of trouble being viewed. One flash = level 1, two flashes = level 2 etc.
Table 9-1 Trouble Conditions
Trouble
Condition
Trouble # Description Trouble Types Trouble # Trouble
Notification
Level 1 Level 2 Level 3
NOTE: Trouble #s are used to identify the number to view the trouble and depending on the keypad type
being used, identifies which LED or digit illuminates to display the trouble. Similarly, Trouble
Notification identifies the range that may be displayed on the keypad. When exploring the trouble
levels, the Trouble indicator will flash to identify which level you are currently viewing.
Service Required
01 Assorted Trouble types.
Time and Date troubles can be resolved by
resetting the Time/Date. To set Time/Date
press .
For all other troubles call for service.
Bell Circuit 01
RF Jam 02
Auxiliary Supply 03
Time and Date 04
Output 1 Fault 05
Battery Trouble
02 The system has detected a battery trouble
condition. Call for service.
Low Battery
(System Label)
01 n/a
No Battery service.
(System Label)
02 n/a
High Current
Output Low Battery
04 Module 1-4
High Current
Output No Battery
05 Module 1-4
Power Supply Low
Battery
07 Module 1-4
Power Supply
No Battery
08 Module 1-4
Bus Voltage
03 The system has detected a trouble condition.
Call for service.
HSM2HOST 01 n/a
Keypad 02 Keypad 1-16
Zone Expander 04 Zone expander 1-15
Power Supply 05 Power supply 1-4
High Current
Output
06 Output terminal 1-4
Output Expander 08 Output module 1-16
AC Troubles
04 The system is experiencing loss of power.
Call for service.
If the building and/or neighborhood has lost
electrical power, the system will continue to
operate on battery for several hours.
Zone 01 Zone label or 001-128
Siren 03 Siren 1-16
Repeater 04 Repeater 1-8
Power Supply 05 Power supply 1-4
High Current
Output
06 Output terminal 1-4
System Label 07 n/a
*
*
2
*
6 0
1
