CADENCE II Fetal Monitor User Manual
- 61 -
Appendix 2 Signal Input/Output Connector
Accessory equipment connected to these interfaces must be certified according to the respective
IEC/EN standards (e.g. IEC/EN 60950 for data processing equipment and IEC/EN 60601-1 for
medical equipment). Furthermore all configurations shall comply with the valid version of the
system standard IEC/EN 60601-1-1. Everybody who connects additional equipment to the signal
input connector or signal output connector configures a medical system, and is therefore
responsible that the system complies with the requirements of the valid version of the system
standard IEC/EN 60601-1-1. If in doubt, contact our technical service department or your local
distributor.
DB9 Interface
Pin Signal Input/Output
1 +5V Output
2 Rx Input
3 Tx Output
4 485EN Input
5 0V Ref.
6 TA Output
7 TB Output
8 RA Input
9 RB Input
