264
EMC Symmetrix DMX-3 Product Guide
Symmetrix DMX-3 Specifications
Physical data
The Symmetrix DMX-3 supports configurations of one system bay
and from one to eight storage bays. Table 40 on page 264 through
Table 42 on page 265 contain the physical data for the DMX-3 system.
Table 40 Physical specifications
Description System bay measurements Storage bay measurements
Dimensions
Height 76.66 in (194.7 cm)
a
76.66 in (194.7 cm)
a
Width 24.02 in (61.0 cm) 30.20 in (76.3 cm)
Depth 41.16 in (104.5 cm) 41.88 in (106.4 cm)
Clearance for Service and Airflow
Front 42 in (106.7 cm) 42 in (106.7 cm)
Rear 42 in (106.7 cm) 42 in (106.7 cm)
Top 18 in (45.7 cm) 18 in (45.7 cm)
a. This measurement includes the top trim piece. Without the trim piece, the system bay height is 74.90 in.
(190.25 cm).
Table 41 Multibay width measurements
a
System bay and storage bay configurations
System bay and
Storage bay widths
System bay and one storage bay 54.47 in (137.9 cm)
System bay and two storage bays 84.92 in (214.8 cm)
System bay and three storage bays 115.37 in (291.7 cm)
System bay and four storage bays 145.82 in (368.6 cm)
System bay and five storage bays 176.27 in (445.5 cm)
System bay and six storage bays 206.72 in (522.4 cm)
System bay and seven storage bays 237.17 in (599.3 cm)
System bay and eight storage bays 267.62 in (676.2 cm)
a. .25 in (0.6 cm) added for gap between each bay.
