EMC Symmetrix DMX-3 User Manual

272
EMC Symmetrix DMX-3 Product Guide
Symmetrix DMX-3 Specifications
Figure 62 EMC model number DMX3-PCBL3DHR cable description
Figure 63 EMC model number DMX3-PCBL3DHH cable description
P1 P2
CS8364 Russellstoll 9P54U2
Marker, label ID
180.0” +/- 6.0”
(15 ft)
CS8364 Russellstoll
9P54U2
Color
BLK
WHT
RED
GRN
From
P1-X
P1-Y
P1-Z
P1-G
To
P2-X
P2-Y
P2-Z
P2-G
Signal
L1
L2
L3
GND
SYM-001095 PG
DMX3-PCBL3DHR three-phase, four-wire 50 AMP
(200~240 VAC line-to-line) (Delta)
P1 P2
CS8364 CS8365
Marker, label ID
180.0” +/- 6.0”
(15 ft)
CS8364 CS8365
Color
BLK
WHT
RED
GRN
From
P1-X
P1-Y
P1-Z
P1-G
To
P2-X
P2-Y
P2-Z
P2-G
Signal
L1
L2
L3
GND
SYM-001092 PG
DMX3-PCBL3DHH three-phase, four-wire 50 AMP
(200~240 VAC line-to-line) (Delta)
Y
Z
Z X
X
Y
