Electrical specifications and power requirements
271
Symmetrix DMX-3 Specifications
North American
power
specifications
Table 49 on page 271 describes the electrical specifications for the
Symmetrix DMX-3 system bay and storage bays for systems installed
in North American, three-phase, Delta environments.
North American
extension cords and
mating connectors
Each DMX-3 system bay and storage bay has two PDPs with a power
cable affixed to each PDP shown in Figure 61 on page 270. For a
North American, three-phase, four-wire configuration, affixed to each
PDP power cable is a 50A Hubbell CS8365C or an equivalent 8365
type connector (Delta). Table 50 on page 271 describes the optional
EMC extension cords that connect to this Hubbell connector and
mating connector options.
Table 49 Electrical specifications, North American, three-phase, four-wire
(Delta)
Specification North American three-phase (Delta)
Input nominal voltage
a
200–240 VAC L-L nom (208 VAC optimal)
Range 200
–240 VAC + 10%
Frequency 50
–60 Hz
Circuit breakers 50 A
Power zones Two
Power requirements at customer site (minimum) Two 50 A three-phase drops per bay
a. An imbalance of AC input currents may exist on the three-phase power source feeding the Symmetrix system, depending on configuration.
The customer's electrician must be alerted to this possible condition to balance the phase-by-phase loading within the customer's data
center.
Table 50 Extension line cord, North American, three-phase, four-wire (Delta)
Extension line cord description
Extension line cord
EMC model number
Mating connector
EMC model number
and vendor part number
Three-phase, four-wire, 15 ft line cord with connectors on each end (Delta).
• Connector CS8364C mates to the four-wire, DMX-3 system bay or
storage bay power cord connector Hubbell CS8365C or an equivalent
8365 type connector.
• Thomas and Betts/Russellstoll 9P54U2 connector can mate to the
optional EMC Russellstoll mating connector or customer-supplied cables.
EMC model number:
DMX3-PCBL3DHR
(Figure 62 on
page 272)
EMC model number:
DMX-ACON3P-50 rated
up to 50A.
Vendor part number:
Russellstoll 9C54U2T
Three-phase, four-wire, 15 ft line cord with connectors on each end (Delta).
• Connector CS8364C mates to the four-wire, DMX-3 system bay or
storage bay power cord connector Hubbell CS8365C or an equivalent
8365 type connector.
• Connector CS8365C can mate to customer-supplied Hubbell CS8364 or
an equivalent type connector or extension cord.
EMC model number:
DMX3-PCBL3DHH
(Figure 63 on
page 272)
Customer-supplied
Hubbell CS8364 or
equivalent.
No EMC mating connector
available.
