Emerson Process Management GmbH & Co. OHG2-12
X-STREAM Non-Incendive
Instruction Manual
HASXENE-IM-EX
12/2014
EXPLOSION AND ELECTRICAL SHOCK HAZARD
All power and signal cables must end in a safe area or within a protective
enclosure (e.g. Ex e enclosure)!
Verify the power cord is layed with a distance of at least 1 cm (0.4 in) to any
signal cable to ensure proper insulation from signal circuits!
The number of actually available signal out-
puts, and also the number of built-in modules
with screw-type terminals, varies according to
the confi guration of the unit.
A maximum of three modules with 36 termi-
nals each can be fi tted.
The terminals can be accessed by opening
the front panel of the instrument.
2.7 Installation - Electrical
Characteristics of terminals:
Accepted wire gauge: 0.14…1.5 mm
2
(26 AWG…16 AWG),
end sleeves not required
Skinning length: 5 mm (0.2")
Thread: M2
Min. tightening torque: 0.25 Nm (2.21 in.lb)
