19
Chapter 1 Product Overview
Part Names and Functions
Body
1 Roll paper cover Open this cover when installing or replacing the roll paper.
2 USB-C connector Connects a USB-C cable.
3 Cover open lever Operate this lever to open the roll paper cover.
4 Operation panel There are buttons to operate the printer and LEDs to display the printer status.
5 Manual cutter A cutter for cutting roll paper.
6 Belt clip A clip for hanging the printer from a waist belt.
7 Battery Provides electricity to the printer. The printer does not work without the battery
installed.
8 NFC Tag A mark is printed here to indicate the position of the NFC tag. Bring an NFC-compatible
device close to the mark to obtain information about the printer. For the functions
using the NFC tag, refer to "Useful Functions for Smart Devices" on page 32.
To Next Page
