Epson SC-P7000 Series User Manual

Icon Explanation
Widest is selected
4.Roll Paper Margin
Displays the value set for Roll Paper Margin.
❏ Auto: Standard is set
❏ 15mm: Top15mm/Bottom15mm is set
❏ 35/15mm: Top35mm/Bottom15mm is set
❏ 150/15mm: Top150mm/Bottom15mm is set
❏ 3mm: 3mm is set
❏ 15mm: 15mm is set
U “Paper” on page 116
5. Approximate amount of ink remaining for each
color
Displays the amount of ink remaining for each color.
Ink codes
SC-P9000 Series/SC-P7000 Series
CCyan
OR Orange
YYellow
LC Light Cyan
MK Matte Black
PK Photo Black
VM Vivid Magenta
LK Light Black
GR Green
LLK/V
*
Light Light Black/Violet
VLM Vivid Light Magenta
* The display differs depending on the inksets being used.
SC-P8000 Series/SC-P6000 Series
CCyan
YYellow
SC-P8000 Series/SC-P6000 Series
LC Light Cyan
MK Matte Black
PK Photo Black
VM Vivid Magenta
LK Light Black
LLK Light Light Black
VLM Vivid Light Magenta
Ink remaining (using Cyan as an example)
Icon Ink Remaining in Cartridge
No error. The height of the indicator
changes with the level of ink remaining.
Ink is low. You need to prepare a new ink
cartridge.
Ink cartridge is expended; replace with a
new ink cartridge.
An error occurred. Check the message on
the screen, and clear the error.
6. Usage status of optional item
Displays the availability of optional item.
Nothing is displayed when the item is not connected.
Auto take-up reel unit
*
* Only SC-P9000 Series/SC-P8000 Series are supported
Icon Status
Available
Not Available
SpectroProofer Mounter 24"/44"
Icon Status
Available
SC-P9000 Series/SC-P7000 Series/SC-P8000 Series/SC-P6000 Series User's Guide
Introduction
15
