FAAC E045 User Manual

E045 10 732786 - Rev.C
ENGLISH
4.4 J9 - ACCESSORIES POWER SUPPLY
15
- GND Accessories power supply negative
16
17
+ +24 Accessories power supply positive (MAX. load = 500mA)
18
4.5 J11 - INDICATOR LIGHT/ELECTRIC LOCK OUTPUTS
20 W.L.
Indicator Light Output
24 V
"
- MAX Load 100mA
21 LOCK
Electric lock (12 V~ or 24 V
"
)
operated 2 sec before opening
of leaf 1
When
BUS-2EASY encoder is disabled, the electric
lock is operated before each opening (in whatever
position the leaf is in).
When
BUS-2EASY encoder is enabled, the electric
lock is operated before opening, only if the leaf is
closed position.
