FAAC E045 User Manual

E045 26 732786 - Rev.C
ENGLISH
5.4 TIME LEARNING - SETUP
When the board is powered, if a SETUP has never been performed, or if the board requests it, on the
display
S0 indicates that a SETUP must be performed.
During SETUP, the connected BUS-2EASY accessories are always entered.
The BUS-2EASY encoders are to be enabled before SETUP: set the parameter En = Y (see
BASIC Programming)
For SETUP, proceed as follows:
During SETUP all safety devices are disabled! Therefore, carry out the operation avoiding
any transit in the leaf movement area.
If a system without an encoder is installed, mechanical stops will be required for the leaves.
1. Enter BASIC programming and go to the parameter
tL, when F is released -- will appear.
2. Ensure that the gate leaves are closed. Otherwise, proceed as follows:
- Press and hold -/R2 to close leaf 2
- Press and hold +/R1 to close leaf 1
Should pressing +/R1 and/or -/R2 command opening of the corresponding leaf, cut off power
and, on terminal board J2, invert the phase cables of the corresponding motor (terminals 2-3
for leaf 1 motor and terminals 5-6 for leaf 2 motor).
3. With the gate leaves closed, launch SETUP by pressing and holding
+
and
-
until S1 begins to
flash on the display (about 3 sec).
4. Release
+
e
-
. Leaf 1 begins its opening movement.
Operation WITHOUT Encoder
Stop movement by sending an OPEN A
pulse as soon as leaf 1 reaches the contact
point.
Operation WITH Encoder
Leaf 1 will stop as soon as it reaches the
contact point. If there is no mechanical
stop, stop the leaf movement at the desired
point by sending an OPEN A pulse.
5. On the display
S2
will flash (only if 2 motors have been selected): leaf 2 begins opening.
Operation WITHOUT Encoder
Stop movement by sending an OPEN A
pulse as soon as leaf 2 reaches the contact
point.
Operation WITH Encoder
Leaf 2 will stop as soon as it reaches the
contact point. If there is no mechanical
stop, stop the leaf movement at the desired
point by sending an OPEN A pulse.
6. On the display
S3 will flash (only if 2 motors have been selected): leaf 2 begins closing.
Operation WITHOUT Encoder
Stop movement by sending an OPEN A
pulse as soon as leaf 2 reaches the contact
point.
Operation WITH Encoder
Leaf 2 will stop as soon as it reaches the
contact point. If there is no mechanical
stop, stop the leaf movement at the de-
sired point by sending an OPEN A pulse.
