Fronius MagicWave 2200 Job User Manual

135
EN
MagicWave
4000 / 5000 Job
Primary continuous power (100% d.c.
2)
)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
4.8 kVA
4.4 kVA
3.9 kVA
5.1 kVA
4.9 kVA
4.3 kVA
Cos phi 0,99 0,99
Welding current range (3-phase)
TIG 3 - 250 A 3 - 300 A
Electrode 10 - 250 A 10 - 300 A
Welding current range (single phase)
TIG 3 - 220 A 3 - 220 A
Electrode 10 - 180 A 10 - 180 A
Welding current at 3 x 400 - 460 V
10 min/40 °C (104 °F) 35% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 40% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
180 A 190 A
Welding current at 3 x 200 - 240 V
10 min/40 °C (104 °F) 30% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 35% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
160 A 180 A
Welding current at 1 x 200 - 240 V
10 min/40 °C (104 °F) 40% d.c.
2)
220 A -
10 min/40 °C (104 °F) 50% d.c.
2)
- 220 A
10 min/40 °C (104 °F) 100% d.c.
2)
150 A 160 A
Open circuit voltage 89 V 89 V
Working voltage
TIG 10.1 - 20.0 V 10.1 - 22.0 V
Electrode 20.4 - 30.0 V 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class B B
EMC emission class
(in accordance with EN/IEC 60974-10)
A A
Dimensions L x W x H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 28.2 kg
62.17 lb.
30 kg
66.14 lb
Mark of conformity S, CE S, CE
MW 2500 Job MV MW 3000 Job MV
MW 4000 Job MW 5000 Job
Mains voltage 3 x 400 V 3 x 400 V
Mains voltage tolerance ± 15 % ± 15 %
Mains frequency 50/60 Hz 50/60 Hz
