Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
"Connecting the power cord" on page 56
.
▶
"Switching on the server" on page 58.
7.5 2.5-inch HDD/SSD configurations
7.5.1 Overview of configurations
7.5.1.1 Configuration with up to four HDD/SSD modules
Figure 69: Configuration with up to four 2.5-inch HDDs/SSDs
Position Logical drive
number
ServerView RAID Manager display
name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
Configuration with the 4x 2.5-inch PCIe SSD backplane
Position Logical drive
number
ServerView RAID Manager display
name
[0] ‐ Vendor Product (0)
[1] ‐ Vendor Product (1)
[2] ‐ Vendor Product (2)
[3] ‐ Vendor Product (3)
Hard disk drive (HDD) / solid state drive (SSD)
