5.3.20 Performing a fan test
Notes on replacing a defective fan
After replacing a defective system fan or PSU containing a defective fan,
the fan error indicators will stay lit until the next fan test. By default, a fan
test is automatically started every 24 hours. The first automatic fan test
being performed after replacing a fan will turn off the fan error indicator
.
If you want to start the fan test manually, you can do so by following the
description below:
Executing the fan test via the iRMC S5 web interface
â–¶
Log into the iRMC S5 web interface.
The System menu is displayed on default.
â–¶
Open the Cooling page.
â–¶
Expand the Cooling Devices group.
â–¶
Click
Start Fan Test.
For more information on iRMC settings, see the iRMC user guides.
Executing the fan test via ServerView Operations Manager
â–¶
Open the ServerView Operations Manager and log in.
â–¶
Under
Administration select Server Configuration.
â–¶
In the hierarchy tree of the Server list tab, select the server to be
configured.
â–¶
In the right-hand side of the window, specify the details on the selected
server and confirm your entries by clicking GO.... In the left-hand section of
the window, the Configuration tab is being activated.
â–¶
In the navigation area of the Configuration tab, select Other Settings.
â–¶
Under Daily Fan Test, set the daily fan test time to a few minutes from the
current time. (Ensure to note down your previous setting.)
Basic software procedures
96 Upgrade and Maintenance Manual RX1330 M4
