Figure 109: Installing the secondary SFP+ transceiver module
â–¶
If applicable, install the secondary SFP+ transceiver module accordingly.
9.4.2 Removing SFP+ transceiver modules
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
A network adapter is equipped with one or two SFP+ (small form-factor
pluggable) transceiver modules. SFP+ transceiver modules are hot-pluggable.
Expansion cards and backup units
RX1330 M4 Upgrade and Maintenance Manual 193
