Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Removing the defective 2.5-inch HDD/SSD module
▶
Remove the HDD/SSD module, see "Removing a 2.5-inch HDD/SSD
module" on page 156
.
▶
If applicable, remove the HDD/SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page 135.
Installing the new 2.5-inch HDD module
▶
If applicable, install the HDD/SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 135.
▶
Install the HDD/SSD module, see "Installing 2.5-inch HDD/SSD modules"
on page 152.
Concluding steps
▶
If the HDD/SSD is configured using a RAID controller with a RAID level
higher than "0", the rebuild will start automatically, see "Performing a RAID
array rebuild" on page 87.
7.5.5 Replacing the 4 x 2.5-inch HDD backplane (left
side)
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 43.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Hard disk drive (HDD) / solid state drive (SSD)
RX1330 M4 Upgrade and Maintenance Manual 159
