Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 61
.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
9.5.5 Replacing a TFM
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Locating the defective server" on page
43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the defective TFM
▶
Remove the depending expansion card, see "Removing an expansion card"
on page 203.
Expansion cards and backup units
RX1330 M4 Upgrade and Maintenance Manual 209
