Fujitsu STYLISTIC V535 User Manual

Technical da ta
Technical data
Tablet PC
General
Processor
Intel® Atom® Z3795 or Z3745 Quad-core
Main memory (o n-board memory and storage
capacity)
4GB RAM & 64GB or 1 28 G B SSD eMMC
Electrical data
Safety regulations complied with CE, UL/cUL
Protection class II
Maximum power consumption (Tablet PC
switched on and the battery fully charged):
Max. 11.6 W (DC 3.8 V / 3 A)
Touchscreen
Size 8.3” / 21 cm
Screen resolution 1920 x 1200 pixels/16 million colors
Pixel cla ss II
Technology Wide-View High-Bright Display with LED
background lighting
Digitizer and glass panel
Glare capacitive touch panel
Cameras
• Front: 2 megapixels
• Back: 8 meg
apixels, autofocus, mobile light
Graphics card
Chip Intel® H D graphics
Maximum
resolution of external display:
1920 x 10
80 (1080 p)
Dimens
ions
Width
x Depth x Height
227.8 x 150.1 x 12.7 mm / 9 in x 5.9 in x 0.5 in
Weight depending on configuration approx. 1.2 lbs. (540 g)
Input d evices
Tablet buttons 3 keys
Sl
ots
Storage card slot 1 x micro S D Card
Ports
Audio combo jack (mic / headpho nes)
3.5mmstereominijack
Dock ing port 1 x
USB (Universal Serial Bus) 1 x USB 2.0
Ambient conditions
Operating temperature -10 °C to +50 °C / 14 °F to 122 °F
Transport temperature (2K2) -20 °C to +60 °C / -4 °F to 140 °F
76 Fujitsu

Fujitsu STYLISTIC V535 Specifications

General

Stepping	C0
Processor code	SR1SK
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Motherboard chipset	Intel BayTrail-T SoC
Processor frequency	1.59 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.39 GHz
Processor operating modes	32-bit, 64-bit
Scenario Design Power (SDP)	2 W
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	-
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	64 GB
Display diagonal	8.3 \
Touch technology	Multi-touch
Display brightness	400 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Graphics card	HD Graphics
Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	2 MP
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Microphone in	No
USB 2.0 ports quantity	1
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Cable lock slot type	Kensington
Sustainability certificates	RoHS
Certification	CE, EN 60950, IT-Eco-Declaration, RoHS, WEEE, GOST
Battery capacity	4425 mAh
Battery life (max)	6.5 h
Battery recharge time	5 h
AC adapter power	36 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3 A
AC adapter output voltage	12 V
Platform	Windows
Operating system version	64
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Processor ARK ID	80267
Processor socket	BGA 1380

Weight and Dimensions

Depth	12.5 mm
Width	227.8 mm
Height	150.1 mm
Weight	540 g
