Fujitsu STYLISTIC V535 User Manual

Technical da ta
Actual throughput may vary depending on environmental factors:
Extended Low Temperatu re Restrictions:
1. LCD response time maybe slower at or below 0° C (+32° F).
2. Battery will not charge below 0° C (+32° F).
3. Battery life will be significantly reduced (> 50%) when un it is
operated at or below 0° C (+32° F).
4. Unit should not be operated below 0° C ( +32° F).
Extended High Temperature R estrictions:
1. Unit should not be opera ted above +50° C (+122° F).
2. Depending on its load, CPU performance may be reduced at
temperatures greater than +35° C ( +95° F).
3. Camera noise may occur a t temperatures greate r than +35° C (+95° F).
4. Battery charging will be limited at te mperatures greater than +35° C (+95° F).
WLAN specifications
Type of network Broadcom Dual Band 11a/b/g/n
Transf er rate (Automatic switch
ing) IEEE802.11 a an d g: 54
Mbps max. data rate
; IEEE802.11n: 300 Mbps
max. data rate, IE
EE802.11ac: 867 Mbps max.
data rate
Active frequency • 802.11n: 2.4 GHz or 5 G Hz
• 802.11b/g: 2400~2482 MHz
• 802.11a: 5150~5850 MH z
Number o f channels
• 802.11a: 24 independent channels
• 802.11b/g: 1 3 channels, 3 non-overlapping
channels
• 802.11n: Channel bonding takes two of
the non-overlapping 20MHz channels and
combines them into one 40MH z channel. It
is actually 12 non-overlapping c han nels with
channel bonding and 24 without. Also it is 2
non-overlapping channel in 2.4GHz when
channel bonding is used.
Security
Encryption types: compatible with WEP, TKIP,
AES*, WPA 1.0 and WPA 2.0
Encryption key, lengths supported: 64 bits and
128 bits
Maximum recommended number of computers
to be connected over wireless LAN (during ad
hoc connection)
10 units or less **
*Net
work key encryption (WEP) occurs with the number of bits given above, after deduction of the
fixe
d length o f 24 bits the user may however also se t 40 or 104 bits.
** D
epending on the particular practical application, the number of computers which can be
ne
tworked is reduced if necessary.
Fujitsu 77

Fujitsu STYLISTIC V535 Specifications

General

Stepping	C0
Processor code	SR1SK
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Motherboard chipset	Intel BayTrail-T SoC
Processor frequency	1.59 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.39 GHz
Processor operating modes	32-bit, 64-bit
Scenario Design Power (SDP)	2 W
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	-
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	64 GB
Display diagonal	8.3 \
Touch technology	Multi-touch
Display brightness	400 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Graphics card	HD Graphics
Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	2 MP
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Microphone in	No
USB 2.0 ports quantity	1
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Cable lock slot type	Kensington
Sustainability certificates	RoHS
Certification	CE, EN 60950, IT-Eco-Declaration, RoHS, WEEE, GOST
Battery capacity	4425 mAh
Battery life (max)	6.5 h
Battery recharge time	5 h
AC adapter power	36 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3 A
AC adapter output voltage	12 V
Platform	Windows
Operating system version	64
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Processor ARK ID	80267
Processor socket	BGA 1380

Weight and Dimensions

Depth	12.5 mm
Width	227.8 mm
Height	150.1 mm
Weight	540 g
