3. SETTING AND ADJUSTMENT
3-9
Scanner setting
1. Open the INITIALIZE menu described on page 3-2.
2. Press [3] key to open the SCANNER menu.
[SCANNER]
1 BACK
2 BLIND SECTOR 1
START 000°
ANGLE 000°
3 BLIND SECTOR 2
START 000°
ANGLE 000°
4 ANT REVOLUTION
LO/HI/AUTO
5 ANT SW
OFF/ON/EXT
6 ANT STOPPED
STBY/TX
7 M SPEC
OFF/ON
8 BB TYPE
NORMAL/BB
9 [DUAL RADAR]*
Note 1: Set the blind sector as minimum as possible.
Note 2: Do not set the blind sector in the bow direction.
*non IMO-type only
To close the menu, press the [MENU] key.
BLIND SECTOR 1 and BLIND SECTOR 2
Set area (up to 2) where no radar pulses will be transmitted, and heading should be
adjusted before setting any blind sector. For example, set the area where an interfering
object at the rear of the scanner would produce a dead sector (area where no echoes
appear) on the display. To enter an area, enter start bearing relative the heading and dead
sector angle. To erase the area, enter 0 for both the START and ANGLE sections. The
setting range of START is 0 to 359° and ANGLE is 0 to 180°.
ANT REVOLUTION
This menu item is used for 42 rpm antenna unit. The default is AUTO, where antenna
revolution speed is high for short range setting and low speed for long range setting. When
LO is selected, the antenna always rotate in 36 rpm, and HI, 42 rpm.
ANT SW and ANT STOPPED
This is used for antenna maintenance by serviceman.
Note: Choose OFF at ANT SW to prevent the antenna rotation. As for ANT STOPPED,
choose STBY to prevent transmission while the antenna is stopped.
M SPEC and BB TYPE
Not used.
DUAL RADAR
See section 3.7.
