Furuno 2127 User Manual

4. INSTALLING OPTIONAL EQUIPMENT
4-19
Cable fabrication
RW-9600
6
14
5
9
approx. 450
5
20
Armor
Units: mm
Shield
Vinyl sheath
Pull out inner cables from here.
Shield
Coaxial cable
Crimp on lug for M8
DPYC-6 and TTYC-4
20
5
6
DPYC-6: approx. 130
TTYCY-4: approx. 150
Conductor
S = 0.75 mm
= 1.11 mm
2
TTYCY-4 (Four twisted pairs)
Armor
Sheath
= 17.7 mm
Sheath
Conductor
S = 6 mm
I = 3.12 mm
2
DPYCY-6
Armor
Sheath
I = 13.9 mm
Armor
Vinyl sheath
Taper for unused wires.
I
I
RG-12/UY
20
60
14
9
5
Vinyl sheath Armor
Inner conductor
Outer conductor
