3. SETTING AND ADJUSTMENT
3-15
OTHER menu setting
Open the OTHER menu by pressing [8] key on the INITIALIZE menu.
[OTHERS]
1BACK
2 DEMO ECHO
OFF/EG/TT-TEST/PC
3 EAV W/O GYRO
OFF/ON
4 TT CATEGORY SELECT
CAT1/CAT2 3
5 INS
OFF/SERIAL/LAN
EAV w/o GYRO
If a gyrocompass is not connected, choose the echo average function, ON (working) or OFF
(no working).
TT CATEGORY SELECT
Choose CAT1 or CAT2•3 depending on your ship’s size.
CAT1: All ships over than 10,000 GT
CAT2: All ships between 500 and 10,000 GT
CAT3: All ships less than 500 GT
INS
Choose appropriate item according to the ECDIS connected.
OFF: No connection
SERIAL: When connecting FEA-2105 series ECDIS.
LAN: When connecting FEA-2107 series ECDIS.
