Furuno FAR-2117 Service Manual

1.3 Specifications
1-17
Table 1.3.3 Transmitted Pulse Width and PRF
Range (NM)
Pulse
Width
(u-sec)
0.125 0.25 0.5 0.75 1.5 3 6 12 24 48 96
S1: 0.07
B.W: 40 MHz
PRF: 3000 Hz
*ARPA 32 NM: 2200 Hz
*2nd: 3000 Hz
S2: 0.15
B.W: 40 MHz
PRF: 3000 Hz
*ARPA 32 NM: 2200 Hz
*2nd: 3000 Hz
M1: 0.3
B.W: 10 MHz
PRF: 1500 Hz
*2nd: 500 Hz
M2: 0.5
B.W: 10 MHz
PRF: 1000 Hz
*2nd: 500 Hz
M3: 0.7
B.W: 10 MHz
PRF: 1000 Hz
*2nd: 500 Hz
L : 1.2
B.W: 3 MHz
PRF: 500 Hz
*2nd: 500 Hz
Note:
- B.W (Band Width):
IF frequency: Receiving bandwidth of 60 MHz.
- PRF (Pulse Repetition Frequency):
The Repetition Frequency is not constant to avoid Radar interface from other radars.
The Jamming range is approximately± 10 % of the Repetition Frequency. When the
Antenna is stopped, the Repetition Frequency is constant.
- ARPA 32NM:
The Repetition Frequency is changed when the ARPA tracking distance is set to
32 NM on [Menu] -> 0 -> 6 -> 9: MAX RENGE.
- 2nd: Repetition Frequency of the 2
nd
trace mode
The Repetition Frequency is changed when the setting on [Menu] -> 1 -> 1: 2ND
ECHO REJ is ON.
