AP 1.3 Configuration of the Sentence from
AP 1.3 Configuration of the Sentence from AP 1.3 Configuration of the Sentence from
AP 1.3 Configuration of the Sentence from ARPA
ARPAARPA
ARPA(FAR) to ECDIS(FEA.)
(FAR) to ECDIS(FEA.)(FAR) to ECDIS(FEA.)
(FAR) to ECDIS(FEA.)
AP1-22
1.3.5 RSD - Radar System Data
$RARSD , x.x , x.x , x.x , x.x , x.x , x.x , x.x , x.x , x.x , x.x , x.x , a , a *hh<CR>
1 2 3 4 5 6 7 8 9 10 11 12 13
Contents Data Disp. rota.
1 Origin1 range
2 Origin1 bearing
3 VRM1, range
4 EBL1, degrees
5 Origin2 range
6 Origin2 bearing
7 VRM2, range
8 EBL2, degrees
9 Cursor range
10 Cursor bearing
11 Range scale
12 Range units
- TRACK BALL
BEARING
RANGE
- EBL
BEARING
- VRM
RANGE
- STATUS
DISPLAY,
TRANSMITTER,
ANTENNA,
TRACKING,
ETC...
13 Disp. rota.
C= course up
H= head up
N= north up
