4.4
Initialize Setting
Initialize Setting Initialize Setting
Initialize Setting
4-27
Table 4.4.6 Functions for Radar Type
Differences in Functions Type Functions
IMO, A 0.125/0.25/0.5/0.75/1.5/3/6/12/24/48/96
Range
B, C
0.125/0.25/0.5/0.75/1.5/3/4/6/8/12/16/24/32/48/96
IMO, A Rader/Rader+Plotter
Handling of chart
B, C Rader/Plotter/Rader+Plotter
IMO IEC61162 2
nd
ED NMEA Ver-3.0 (Equivalent)
NAV data
A, B, C IEC61162 NMEA Ver-1.5 (Equivalent)
IMO
DATUM error is displayed when there is no DTM (WSG-84)
sentence.
When handling DTM
Sentence error
A, B, C
DATUM error is not displayed even when there is no DTM sentence.
However, when DTM data is discontinued, DATUM error is
displayed.
IMO
When DTM is WGS-84, ON/OFF of “[Menu]->4->8:
AIS FUNCTION” is enabled. When DTM is other than WGS-84, AIS
function is turned off.
When handling AIS
display, there is no DTM
sentence error.
A, B, C No restriction
IMO EPFS error is displayed. EPFS error display when
GPS accuracy is changed.
A, B, C EPFS error is not displayed.
IMO
ALARM 1 is set in a range of 3 to 6 NM. There is no restriction on
the range of ALARM 2.
Range of Alarm Zone
A, B, C There is no restriction either on ALARM 1 and ALARM 2.
IMO, A One (1)
Cursor data box
B, C
When “3: SET DRIFT” is set to OFF in the [SPD] icon menu, one
more cursor data box is added.
To Next Page
