5. INMARSAT COMMUNICATIONS
5-20
5.3 Communication Log
The [Communication Log] stores the particulars of the latest 50 received and sent
messages. When the log becomes full, the oldest message is automatically deleted.
5.3.1 How to display and print the communication log
1. Press the F6 and 4 keys to display the [Communication Log].
2. To scroll the log, use the ↓ key.
3. To print the log, press the P key while pressing and holding down the Ctrl key. To
stop printing, press the Esc key.
Communication Log description
5.3.2 How to automatically print the communication log
1. Press the F8 and 5 keys to show the [Auto Mode Setup] menu.
2. Select [Auto Communication Log Print] then press the Enter key.
3. Select [ON] to automatically print the log then press the Enter key.
4. Long-press the Esc key to return to the standby display.
001 -:
S/R:
Cate:
Type:
Ch:
Ch-Num:
Pri:
LES
Size:
St:
Op. TIme:
Date & Time:
Log no.
S: Sent message, R: Received message
Category (MSG, EGC, DR, EDR, PADR, EPADR, POLL)
Message type (Telex, e-mail, etc.)
Channel type (TDM, SIG, etc.)
5-digit channel number
Normal
ID of LES that handled the message
Size of message (in Bytes)
Communication results. S, Success; F, Failed
Total operating time (in sec) since commissioning
Date and time the message was sent.
Communication Log
No. S/R Cate Type Ch Ch-Num Pri LES Size St Op. Time Date & Time
001 S MSG TLX MSG 11100 Dis 322 10 S 0031104000 Dec-25-2011 17:46
002 R POLL DND TDM 11200 322 10 0031104061 Dec-25-2011 17:44
003 S DR DND SIG 11300 322 10 S 0031104122 Dec-25-2011 17:43
004
005
006
007
008
009
010
[Ctrl]+[P]: Print
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
To Next Page
