Appendix
AP2-5
2.4 Specifications of Rectifier and Battery charger
PR-850A
1. GENERAL
(1) Rated Input Voltage 100/110/120/200/220/240 VAC +/-10%
(2) Input Frequency 50/60 Hz
(3) Input Current 15A or less (Input :100V AC / Output 30A)
30A or less (Input :100V AC / Output 60A)
(4) Rated Output Voltage 24VDC +/-10%
(with rated Output Current 30 to 60A)
(5) Rated Output Current 30A continuous
(6) Peak Output Current 60A output within 1mim. (Input AC)
40A output within 1mim. (Input DC)
(7) Ripple Voltage 200 m Vp-p or less (Load :0 to 30A)
(8) Insulation Resistance 500VDC 10M ohms or more between AC
input and chassis
2. Environmental Condition
(1) Ambient Temperature -20
O
C to +55
O
C
(2) Relative Humidity 95 % max.
PR-300
1. GENERAL
(1) Rated Input Voltage 100/110/200/220 VAC +/-10%
(2) Input Frequency 47 to 63 Hz
(3) Input Current 4.1A or less (Input 100V AC / Output 7.5A)
(4) Rush Current 80A or less
(5) Rated Output Voltage 24VDC +/- 3%
(with rated output current 7.5A)
(6) Rated Output Current 7.5A
(7) Peak Output Current 20A
(with rated output current :15A
250msec, duty 50%)
To Next Page
