FS-5000/8000
A3-7
2.3 System channel description
The following describes about some system channels.
9900
Output power of ITU/DSC channels and direct key-in frequencies are preset as
shown below.
Model vs Max. Output Power (*): for Japanese vessels only.
FS-5000 FS-2500* FS-1600* FS-8000
Output Power 400W 250W 150W 800W
9901
Free Any frequencies (1.6065 to 29.9999 MHz) can be transmitted by direct
key-in.
Limited The frequencies in the ITU/DSC and user channels can be transmitted.
ROM Only the frequencies stored in the user channel can be transmitted.
Marine Any frequency in the following bands may be transmitted.
1606.5 - 4438 kHz, 5680 kHz 18780 - 18900 kHz,
6200 - 6525 kHz, 19680 - 19800 kHz,
8100 - 8815 kHz, 22000 - 22855 kHz,
12230 - 13200 kHz, 25070 - 25210 kHz,
16360 - 17410 kHz, 26100 - 26175 kHz
9911
To test the transmitter press [TEST] and [START] keys in this order. The dummy
load (if equipped) is connected automatically and the test signal of 2191kHz,
modulated by two-tone alarm, is sent to the dummy load.
9915
If you select "1" (short), only check data for Ia, Vc, Ic and Pi are displayed
repeatedly every pressing of the [CHECK METER] key.
9916
To enable to lock the keys except for [SEND], [START], [2182], and [2187.5]
keys, select "1" (ON). Then press the * key to turn on the key lock function. First
press of the * key make the keys inactive. (Keyboard Lock [ON]" will be
displayed.)
Select "2" (Intercom call), to use the [*] key for intercom call.
Note that the AF board 05P0356-33 in the Control Unit is required.
