HCEN12630 Revision 07.2015
Program version 1.xx
AK 98™ Dialysis Machine - Functional check 249
Conditions Evaluations & Actions Error codes
Pump enabled by the
protective system.
The blood pump was commanded to run.
The blood pump tacho value is OK but the
rotation indicator has not detected any
movement (first check). Repeat test until
error code is generated.
0510 088 012
Pump enabled by the
protective system.
The blood pump was commanded to run.
The blood pump rotation indicator has
detected movement but tacho value is to low
(second check). Repeat test until error code
is generated.
0510 088 014
Pump disabled by the
control system.
The blood pump was commanded to stop by
the control system. The measured values
from tacho and/or rotation indicator show
that the blood pump is still running. Repeat
test until error code is generated.
0510 088 015
12.6.5 Venous clamp test
The purposes of the Venous clamp test are:
● to verify that the venous clamp can be opened by simultaneous order from both
the protective system and the control system (at start of the clamp test).
● to verify that the protective system can close and then open the venous clamp.
● to verify that the control system can close and then open the venous clamp.
The venous clamp has two independent shut-off paths. The protective system and the
control system must agree to open the venous clamp. If any of them orders the clamp
to be closed, it will be closed.
Conditions Evaluations & Actions Error codes
Clamp opened by the
protective system and
the control system.
If the clamp is not opened, then repeat test
until error code is generated.
0510 088 069
Clamp closed by the
protective system.
If the clamp is not closed, then repeat test
until error code is generated.
0510 088 072
Clamp opened by the
protective system.
If the clamp is not opened, then repeat test
until error code is generated.
0510 088 070
Clamp closed by the
control system.
If the clamp is not closed, then repeat test
until error code is generated.
0510 088 073
Clamp opened by the
control system.
If the clamp is not opened, then repeat test
until error code is generated.
0510 088 071
Table 12-11. Venous clamp test
12.6.6 Arterial clamp test
The purpose of the Arterial Clamp test is to verify that the protective system and the
control system can open and then close the arterial clamp.
The arterial clamp has two shut-off paths. Both the protective system and the control
system must agree to open the arterial clamp.
