Gambro AK 98 Service Manual

76 AK 98™ Dialysis Machine - Technical description
HCEN12630 Revision 07.2015
Program version 1.xx
h (m) P
degass
(mmHg)
3800 -302
3000 -355
2373 -400
2200 -413
2000 -429
1800 -445
1600 -461
1400 -478
1147 -500
1000 -513
800 -532
600 -550
400 -570
200 -590
0 -610
Table 3-2. Degassing pressure as function of altitude
3.3.3.5.3 Degassing Pressure Control System
The Flow Pump generates the negative degassing pressure by pulling the fluid through
the degassing restrictor.
The degassing pressure set point comes from the presets. The default value is -610
mmHg, but can be preset to other values (-300 to -700 mmHg in 5 mmHg steps) in
case the AK 98 dialysis machine is operated at other altitudes than sea level. See the
relation between pressure and altitude in Table 3-2 “Degassing pressure as function of
altitude” on page76.
