28 AK 98™ Dialysis Machine - AK 98™ Installation guide
HCEN12630 Revision 07.2015
Program version 1.xx
2.2.14 Step 14 - Remote panel, RP 98 (option)
2.2.14.1 About RP 98
Figure 2-12. RP 98 - installation
WARNING!
If a remote Operator's Panel has been installed, fluid bags shall be removed from
the infusion stand when transporting (moving) the machine to avoid overbalance.
The fluid bags may be placed on the top tray.
NOTE!
The AK 98 dialysis machine is prepared for installation of the RP 98 remote panel,
either on the left or the right side of the machine.
2.2.14.2 Prepare
Procedure
1) Remove the plastic plug, 100316359, according to Figure 2-13 “Preparation” on
2) Remove the four screws, 100378406, according to Figure 2-13 “Preparation” on
3)
Remove the cover according to Figure 2-13 “Preparation” on page29.
