GFC 600 AFCS Part 23 AML STC Maintenance Manual Page 37
190-01938-00 Revision 13
Installation:
1. Visually inspect the connector to ensure there are no bent or damaged pins. Repair any
damage
2. Place configuration module in position.
3. Insert connector into configuration module.
4. Assembly of the connector is the reverse of disassembly.
5. Checkout per Section 7.5.
6.7 GSA 80/81 Servos
Removal:
1. Gain access to the desired servo(s).
2. Disconnect the servo harness connector.
3. Use a socket or open-ended wrench to loosen and remove the servo attachment bolts.
4. Carefully remove the servo and place a protective cover on the output gear.
5. Place a protective cover over the GSM 86 servo gear box.
