GFC 600 AFCS Part 23 AML STC Maintenance Manual Page 39
190-01938-00 Revision 13
6.8 GSM 86 Servo Gear Box
Removal:
1. Remove the desired servo(s) per Section 6.7.
2. Disconnect the servo cables as shown on the appropriate model-specific installation
manual addendum. Refer to the Master Drawing List 005-01009-01.
3. Use a socket or open-ended wrench to loosen and remove the servo gear box
attachment bolts.
4. Carefully remove the servo gear box(es).
5. Remove the cable retention pins and ring (or cover) and then remove the servo cable
from the capstan.
Installation:
1. Install the servo cable on the capstan, the install the cable retention pins and ring (or
cover). Use the data provided in the appropriate model-specific installation manual
addendum. Refer to the Master Drawing List 005-01009-01.
2. Carefully install the servo gear box(es), using the hardware specified on the model-
specific installation manual addendum.
3. Connect the servo cables as shown on the appropriate model-specific installation
manual addendum. Refer to the Master Drawing List 005-01009-01.
4. If no other maintenance is to be performed, reinstall the servo(s) per Section 6.7.

Garmin GFC 600 Specifications

General

System Type	Digital Autopilot System
Control Wheel Steering (CWS)	Yes
Yaw Damper	Optional
Automatic Trim	Yes
Vertical Navigation (VNAV)	Yes
Level Change (LVL) Mode	Yes
Flight Director	Yes
Safety Features	Overspeed Protection (OSP)
Interface	Interfaces with Garmin navigators and displays
Aircraft Type	Certified aircraft
Control Modes	Includes heading hold, altitude hold, vertical speed, and navigation tracking
Integration	Seamless integration with Garmin avionics
Approval	Certified
