104 • Appendix B - Profibus
B.4. Actual Data Register Numbers (decimal)
Number Parameter Name Description
1 Logic Status
Logic status of ASTAT-XT. 1 indicates:
d15: ASTAT-XT Tripped.
d14: Motor Stopped.
d13: Motor in Soft Stop Process.
d12: Motor in Start Process.
d11: Motor is Running.
d10: Dual_Adjust On.
d9: Motor is running with Energy Save On.
d8: Motor is running at Slow Speed forward.
d7: Motor is running at Slow Speed reverse.
d6: Reserved
d5..d0: Reserved
2 Motor Current Current, % FLA
3 Line Voltage Line voltage, Volts
4 Phase Sequence 1: Correct phase seq. 0: Wrong phase seq.
5 Hardwired inputs
Discrete Hardwired control inputs:
d15..d8: Reserved.
d7: External fault.
d6: Reserved.
d5: Reserved.
d4: D.Adj / S.Spd / Rst (Programmable) Input.
d3: E.Save / Rvrs / Rst (Programmable) Input.
d2: Start Input.
d1: Soft Stop Input.
d0: Stop Input.
6
DIP switch
d15..d8: Reserved.
d7: Prevent Setting Lock - (right-most)
d6: Enlarged Setting Ranges
d5: Language Selection.
d4: Language Selection.
d3: Reserved - Must be set to Off.
d2: Generator Starting - Set to Off.
d1: Reserved.
d0: Min (OFF) / Max display pages- (left most)
10
Frequency Main frequency, Hz
11 Thermistor Resistance Thermistor resistance, tenth Kohm.
17
Logic status at power
fail
Logic status at control power supply turns OFF.
18 Elapsed Run Time Total Hours of motor runs.
19 Number of Starts Total number of starts
20 Last start period Duration of last start, Seconds
21 Last start peak I Peak current during last starting process
22 Time to start After too many starts trip, Seconds
23 Total trips Total number of trips
24 Last Fault number
# of the fault that caused trip.
# Fault
01: Over Temperature
02: Short Circuit Current
03: Overload
04: Under Current
05: Under Voltage
06: Over Voltage
07: Phase Loss
08: Phase Sequence
09: Shorted SCR.
10: Long Start Time
11: Slow Speed Time
