6 ACTUAL VALUES 6.2 STATUS
6
6.2.9 DIGITAL COUNTERS
PATH: ACTUAL VALUES  STATUS  DIGITAL COUNTERS  DIGITAL COUNTERS Counter 1(8)
The present status of the eight digital counters is shown here. The status of each counter, with the user-defined counter
name, includes the accumulated and frozen counts (the count units label will also appear). Also included, is the date and
time stamp for the frozen count. The COUNTER 1 MICROS value refers to the microsecond portion of the time stamp.
6.2.10 SELECTOR SWITCHES
PATH: ACTUAL VALUES  STATUS  SELECTOR SWITCHES
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
6.2.11 FLEX STATES
PATH: ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.2.12 ETHERNET
PATH: ACTUAL VALUES  STATUS  ETHERNET
 DIGITAL COUNTERS
 Counter 1
Counter 1 ACCUM:
0
MESSAGE
Counter 1 FROZEN:
0
MESSAGE
Counter 1 FROZEN:
YYYY/MM/DD HH:MM:SS
MESSAGE
Counter 1 MICROS:
0
 SELECTOR SWITCHES

SELECTOR SWITCH 1
POSITION: 0/7
Range: Current Position / 7
MESSAGE
SELECTOR SWITCH 2
POSITION: 0/7
Range: Current Position / 7
 FLEX STATES

PARAM 1: Off
Off
Range: Off, On
MESSAGE
PARAM 2: Off
Off
Range: Off, On
↓
MESSAGE
PARAM 256: Off
Off
Range: Off, On
 ETHERNET

ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET TRD LINK
STATUS: Fail
Range: Fail, OK
